SiStat Batch process
What will you learn
How to get data from the SiStat web page.
How to delete a table from a database
How to insert a table from a process into a database
Prerequisites
Access to NetiLab application with sufficient permissions.
Corresponding configuration table in database
Basic knowladge of NetFlow module
Introduction
The process consists of seven nodes:
Get Config - The node type is SQL Query. This node retrieves information, with the entered sql query, from the configuration table.
Get SiStat Data Batch - The node type is PX Reader Batch Node. This node retrieves information from the SiStat website.
Drop Table - The node type is SQL Query. This node deletes a table, with the entered sql query, from the database.
Import Table - The node type is SQL Bulk Import . This node inserts a table into the database.
Steps
Steps
For illustrative purposes, in the following steps we will use data from two datasets that exist in the configuration table.
Step 1 : Get Config
Open Get Config - node type(SQL Query ) and configure it as:
{
"connection": "<results>",
"Timeout": 90,
"ResultName": "sistatconfig",
"queries": [
"select * from sistatconfig"
]
}
The configuration table must exist in the database!
Step 2: Get SiStat Data
Open Get SiStat Data - node type( SiStat process ) and configure it as:
{
"Parameters": [
{
"Url": "https://pxweb.stat.si:443/SiStatData/api/v1/sl/Data/0762003S.px",
"TableName": "delovnoSposobni"
},
{
"Url": "https://pxweb.stat.si:443/SiStatData/api/v1/sl/Data/0762003S.px",
"TableName": "dodanaVrednost"
}
]
}These properties are from the configuration table.
Step 3: Drop Tables
Open Drop Tables - node type(SQL Query ) and configure it as:
{
"connection": "<results>",
"Timeout": 90,
"ResultName": "QueryResult",
"queries": [
"DROP TABLE IF EXISTS [dbo].[SiStatDelovnoSposobni];\nDROP TABLE IF EXISTS [dbo].[SiStatDodanaVrednost];\n"
}Step 4: Import Tables
Open Import Tables - node type ( Bulk Insert Multiple ) and configure it as:
{
"Conection": "<results>",
"addColumns": false,
"MissingTable": false,
"TableUploads": [
{
"TableName": "delovnoSposobni",
"ServerName": "SiStatDelovnoSposobni",
"id": null,
"IncludedColumns": []
},
{
"TableName": "dodanaVrednost",
"ServerName": "SiStatDodanaVrednost",
"id": null,
"IncludedColumns": []
}
]
}
